Estimation of the efficiency of the dry method of decontamination of surface contamination of alpha-emitting-radionuclides
- Авторлар: Korenkov I.P.1, Lashchenova T.N.1,2, Shandala N.K.1, Ermakov A.I.3, Mayzik A.B.4
-
Мекемелер:
- A.I. Burnazyan Federal Medical Biophysical Centre
- Peoples’ Friendship University
- NFC Logistics, Joint-Stock Company
- Joint-stock company Academician A.A. Bochvar High-tech Research Institute of Inorganic Materials
- Шығарылым: Том 98, № 8 (2019)
- Беттер: 878-884
- Бөлім: PREVENTIVE MEASURES
- ##submission.datePublished##: 15.08.2019
- URL: https://medjrf.com/0016-9900/article/view/639675
- DOI: https://doi.org/10.47470/0016-9900-2019-98-8-878-884
- ID: 639675
Дәйексөз келтіру
Толық мәтін
Аннотация
The article describes the evaluation of the efficiency of using the technology of dry method of decontamination of α-radionuclides from working surfaces of premises for different materials, equipment and building structures.
Materials and methods. Instruments for measuring of ambient dose equivalent rate (ADER) with a lower limit of 0.03 μSv/h. Specific activity of α-radionuclides in the samples was determined by radiometric, radiochemical and spectrometric methods using standard methods in the accredited laboratory. The measurements in situ were also carried out using the ISOCS «CANBERRA» mobile gamma-ray spectrometry system with high purity germanium detector and a collimator. Technological equipment included industrial vacuum cleaner with nozzles; high-pressure device; packing sets for RAW collection; HEPA filters; personal protective equipment.
Results. Maps of spatial distribution of surface α-contamination in the building was constructed. We performed cluster analysis of data for zoning of contaminated surfaces. The decontamination factor for porous (brick, concrete), smooth (wood, brown tiles, laminate) and sticky (bitumen, mastic) surfaces was determined.
Conclusion. The cluster analysis made it possible to identify 4 levels of surface α- and β- contamination, particles/cm2 ∙ min: zone I - for α- above 50, for β- above 10,000; zone II - for α- 5-50, for β- 2,000-10,000; zone III - for α- no more than 5, for β- 2000; zone IV - corresponds to the background values of the workspace surfaces. The dry decontamination method revealed a high content of fine dust aerosol fraction deposited in the lungs. To increase the efficiency of dust suppression, water aerosol with droplet size of 100 - 400 microns and quartz sand with particle size of 100-200 microns were sprayed at the rate of 200-400 g per 1 m2. The decontamination coefficient depends on the coating material and the level of surface contamination: concrete - 91 to 97.8%; brick - 85-86%, wood - 38.8-53%; brownstone tiles - up to 29%; mastic - 22-28%; bitumen - 15.9-20%. To protect the personnel, radiation-hygienic rationing of PM10 and PM2,5 content is necessary.
Авторлар туралы
Igor Korenkov
A.I. Burnazyan Federal Medical Biophysical Centre
Хат алмасуға жауапты Автор.
Email: korenkovip@yandex.ru
ORCID iD: 0000-0002-5709-0858
M.D., Ph.D. in Medicine, Chief of Radiation Health Physics Laboratory, A.I. Burnazyan Federal Medical Biophysical Centre, Moscow, 123182, Russian Federation.
e-mail: korenkovip@yandex.ru
РесейT. Lashchenova
A.I. Burnazyan Federal Medical Biophysical Centre; Peoples’ Friendship University
Email: noemail@neicon.ru
ORCID iD: 0000-0002-6682-1261
Ресей
N. Shandala
A.I. Burnazyan Federal Medical Biophysical Centre
Email: noemail@neicon.ru
ORCID iD: 0000-0003-1290-3082
Ресей
A. Ermakov
NFC Logistics, Joint-Stock Company
Email: noemail@neicon.ru
Ресей
A. Mayzik
Joint-stock company Academician A.A. Bochvar High-tech Research Institute of Inorganic Materials
Email: noemail@neicon.ru
Ресей
Әдебиет тізімі
- Rodionov V.V., Shcheglov M.Yu. Reagent decontamination of soil materials. Ecological Security. 2006; 1: 40–8. (in Russian)
- Ivanov V.B., Snytin S.Yu. Analysis and assessment of the level of radiological safety of the enterprise “Moscow Polymetallic Plant”. PA “Antek Consulting”. Moscow; 2003. 36 p. (in Russian)
- Teplitsky A.L., Onken A.I., Kistanov E.M. Decontamination of the sites of radioactive impurity of the territory of the industrial site. FSUE “STC “EXPERT” MO RF JSC SMP. M. M.; 2002. 21 p. (in Russian)
- Korenkov I.P., Lashchenova T.N., Neveykin P.P., Shandala N.K. Actual problems of ensuring radiation safety of the population during decommissioning of radiation-hazardous objects and waste areas. Collection of materials VIII International Symposium “Human Ecology and Medical and Biological Safety of the Population”. Hungary–Austria; 20–29 October 2012. (in Russian)
- Barinov A.S., Prozorov L.B., Nikolaev V.B. et al. the Patent RU2211293C2. A method of electrokinetic cleaning of soils from radioactive and toxic materials. Published 27.08.2003, bull. 24. (in Russian)
- Emets E.P., Poluektov V.P., Khrabrov S.A. Method of cleaning metal surfaces from radioactive contamination. Patent for invention. RU 2210123; 10.09.2003. (in Russian)
- The report on carrying-out research of the Preparation and carrying-out of works to prevent large-scale contamination of the Andreeva Bay the Russian research center “Kurchatov Institute”. Moscow; 2000. 45 p. (in Russian)
- Volkov V.G., Volkovich A.G., Ivanov A.P. et al. Main principles and proposals for the decontamination and rehabilitation of radioactively contaminated objects and areas of KCCC. Atomic Energy. 2009; 107, 2: 75–81. (in Russian)
- Volkov V.G., Zvernov YU.A., Ivanov O.P. Decontamination of radioactive contamination of soil in the RRC “Kurchatov Institute”. Atomic energy. 2007; 103, 6: 381–2. (in Russian)
- Mayzik A.B., Kuznetsov A.Yu., Tsovyanov A.G., Korenkov I.P., Lashchenova T.N. Organizational and methodological approaches for the decommissioning of radiation-hazardous objects. ANRI. 2017; 1(88): 55–61. (in Russian)
- SanPiN 2.6.1.2523-09. Norms of radiation safety (NRB-99/2009). Moscow; 2009. (in Russian)
- SP 2.6.1.2612-10. Basic sanitary rules for ensuring radiation safety (OSPORB 99/2010). Moscow; 2010. with changes from 16.09.3013. (in Russian)
- Safronov, V.G., Eminov A.M. The results of the rehabilitation work of the Center TPT and RAR. Collection of works for the 50th anniversary of sue MOSNPO “Radon”. Sergiev Posad; 2010: 90–6. (in Russian)
- Nikolaevsky V.B., Lashchenova T.N., Devkin B.V. Development and testing of the reactant – separation technology, purification of soil. Collection of works for the 50th anniversary of sue MOSNPO “Radon”. Sergiev Posad; 2010: 188–97. (in Russian)
- Ermakov A.I., Semenova S.V., Korenkov I.P., Lashchenova T.N., Mayzik A.B. Radiation-hygienic approaches for the decommissioning of objects contaminated with technogenic α-emitters. ANRI. 2016; 4: 58–65. (in Russian)
- Quick reference chemist. Moscow: State scientific and technical publishing house; 2015. 550 p. (in Russian)
- Simon A.D., Pikalov V.K. Decontamination. Moscow: IzdAt; 1998. 336 p. (in Russian)
- Sorting of RW by categories and assessing their activity. Moscow: Kvant; 2014. (in Russian)
- The standard of the objects of use of atomic energy. Decontamination of equipment and facilities during decommissioning of nuclear- and radiation-hazardous objects (NRHO). Requirements for applications of manufacturing technologies Robusto SRO-P 60542948 00049-2017. (in Russian)
- Alekseev B.V., Egorov B.N. Marchenko V.A. et al. New guide of chemist-technologist. Radioactive materials. P-115 PPO, Professonal. 2009: 11–420. (in Russian)
- Criteria and standards of rehabilitation of territories and objects contaminated by technogenic radionuclides. Manual P 2.6.1.25-07. Moscow: FMBA, 2007: 23. (in Russian)
- Hygienic requirements for ensuring radiation safety of personnel and the public when designing work with spent nuclear fuel and radioactive waste. Guide R-GTP SevRAO-07, SSC IBF-2007. (in Russian)
- Report on the topic “Substantiation of a set of measures to bring the building” B “of JSC” VNIINM “into a radiation-safe state”. Stage III. Moscow; 2014. (in Russian)
- Air quality 7708-2006. Particle size fraction definitions for health-related sampling. (in Russian)
- Air quality 54578-2011. Workplace air quality. Predominantly fibrogenic aerosols. General principles for hygienic regulation, monitoring and evaluation. (in Russian)
- GN 2.1.6.1338-03. Hygienic standards GN 2.1.6.2604-10. Supplement No. 8 to GN 2.1.6.1338-03 “Maximum permissible concentrations (MPC) of pollutants in the atmospheric air of populated areas”. (in Russian)
